MSI B450M-A PRO MAX II AMD AM4 Motherboard

MSI B450M-A PRO MAX II AMD AM4 Motherboard

This MSI motherboard is built to deliver reliable performance, wide compatibility, and essential modern features, making it an excellent choice for budget to mid-range PC builds. Based on the AMD B450 chipset and using the AM4 socket, it supports an extensive range of AMD processors, including Ryzen 1000 through 5000 Series, G-Series APUs, and Athlon processors with Radeon Vega Graphics. This broad CPU support ensures flexibility for users upgrading older systems or building new ones with proven AMD platforms.

Designed in a micro-ATX (mATX) form factor measuring 200mm x 236mm, the motherboard fits comfortably into compact and standard PC cases while still offering key expansion options. It features two DDR4 memory slots supporting up to 64GB of RAM, with speeds ranging from 2667MHz to 4133MHz (OC via A-XMP). Dual-channel memory support enhances system responsiveness, while compatibility with non-ECC and ECC UDIMM memory (running in non-ECC mode) adds versatility.

For graphics and expansion, the board includes a PCIe 3.0 x16 slot for a dedicated GPU and a PCIe 2.0 x1 slot for additional cards. Integrated display outputs include HDMI 1.4 with support for 4K at 24Hz and DVI-D with resolutions up to 1920x1200 at 60Hz, ideal for systems using processors with integrated graphics.

Storage options are well covered with one M.2 slot supporting PCIe 3.0 x4 or SATA SSDs, along with four SATA 6Gb/s ports and RAID 0, 1, and 10 support. Connectivity is further enhanced by a Realtek 2.5Gbps LAN controller, multiple USB 2.0 and USB 3.2 Gen1 ports, and Realtek ALC897 7.1-channel HD audio for immersive sound.

With comprehensive internal headers, TPM 2.0 support, and a 3-year manufacturing warranty, this motherboard offers a dependable, future-ready foundation for everyday computing, home, and gaming systems.

MSI B450M-A PRO MAX II AMD AM4 Motherboard

• Supports AMD Ryzen 1000 to 5000 Series processors and Athlon CPUs with Radeon Vega Graphics on the AM4 socket
• Powered by the reliable AMD B450 chipset for stable performance and compatibility
• Compact mATX form factor (200mm x 236mm) ideal for space-efficient PC builds
• Equipped with Realtek ALC897 codec delivering immersive 7.1-channel HD audio
• Features PCIe 3.0 x16 slot for graphics cards and PCIe 2.0 x1 slot for expansion
• Dual DDR4 memory slots supporting up to 64GB with speeds up to 4133MHz (OC)
• Supports dual-channel, non-ECC and ECC UDIMM memory (non-ECC mode)
• Integrated HDMI 1.4 and DVI-D outputs for processors with built-in graphics
• High-speed storage support with PCIe 3.0 x4 M.2 slot and four SATA 6Gb/s ports
• RAID 0, 1 and 10 support for enhanced storage performance and data protection
• Multiple USB options including USB 3.2 Gen1 and USB 2.0 for versatile connectivity
• Realtek 2.5Gbps LAN controller ensures fast and stable network performance
• Comprehensive internal headers including front panel, audio, USB, COM and TPM
• TPM 2.0 header support for enhanced system security
• Backed by a reliable 3-year manufacturing warranty
