GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard

GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
-8 %
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard
  • Price: 36,410৳
  • special price: 33,500৳
  • Status: In Stock
  • Brands: Gigabyte
  • Model: X870 EAGLE WIFI7
Based on 0 reviews. - Write a review

Discount Price

33,500৳36,410৳
Available payment method

Monthly EMI Price

3,113৳
Ex Tax: 33,500৳
Add To Cart
Buy Now Add to Compare
Add to Wish List Compare this Product
  • Features: Realtek 2.5GbE LAN, MediaTek Wi-Fi 7 MT7925
  • Graphics Output: 1 x HDMI, 2 x USB4 (Type-C)
  • Supported RAM: 4x DDR5, Max 256GB, 8000(OC)
  • Ryzen 9000/ 8000/ 7000 Series Processors for Socket AM5
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
Basic Information
Supported CPU AMD Socket AM5, support for AMD Ryzen 9000, 8000 & 7000 Series Processors
Chipset AMD X870
Form Factor ATX Form Factor; 30.5cm x 24.4cm
Audio Realtek Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel,
Expansion Slots
PCI 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen 900/7000 Series Processors support PCIe 5.0 x16 mode AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
Memory
Type DDR5
Slots 4 DIMMs
Supported Memory Support for DDR5 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Maximum Memory up to 256 GB (64 GB single DIMM capacity) of system memory
Graphics
Graphics Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller: - 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz * Support for DisplayPort 1.4 version and HDR. Integrated Graphics Processor with AMD Radeon™ Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. ** Support native HDMI 2.1 TMDS compatible ports.
Connector & Ports
HDMI 1 x HDMI port
Display Port (s) N/A
USB CPU+ASMedia USB4® controller: - 2 x USB4® USB Type-C® ports on the back panel CPU: - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel - 1 x USB 3.2 Gen 1 port on the back panel CPU+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) - 4 x USB 2.0/1.1 ports available through the internal USB headers
LAN Port Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen™ 8000 Series- Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series- Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs * The M2B_SB connector shares bandwidth with the M2C_SB connector. The M2B_SB connector operates at up to x2 mode when a PCIe SSD is installed in the M2C_SB connector. 4 x SATA 6Gb/s connectors
RAID RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors. RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Internal I/O Ports 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x 4-pin ATX 12V power connector, 1 x CPU fan header, 1 x CPU fan/water cooling pump header, 4 x system fan headers, 3 x addressable RGB Gen2 LED strip headers, 1 x RGB LED strip header, 4 x SATA 6Gb/s connectors, 3 x M.2 Socket 3 connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only), 1 x power button, 1 x reset button, 1 x reset jumper, 1 x Clear CMOS jumper,
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
Others
Special Features Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Manufacturing Warranty 3 Years

GIGABYTE X870 EAGLE WIFI7 DDR5 AMD AM5 ATX Motherboard


The GIGABYTE X870 EAGLE WIFI7 is a versatile and feature-rich ATX motherboard designed to deliver exceptional performance for AMD's AM5 platform. Positioned as a strong contender for a wide range of users, from avid gamers to professional creators, the EAGLE series offers a compelling balance of high-end features and accessibility. Built on the next-generation X870 chipset, it provides a robust and future-proof foundation for AMD Ryzen™ 9000, 8000, and 7000 series processors. Power delivery is a key strength, with a strong digital VRM design that ensures stable and efficient power to the CPU, allowing for reliable performance even under heavy loads. The board features four DDR5 DIMM slots, enabling support for up to 256GB of high-speed DDR5 memory with impressive overclocked speeds, making it a powerful solution for memory-intensive applications. For high-speed connectivity, the X870 EAGLE WIFI7 is a standout. It includes a PCIe 5.0 x16 slot, providing ample bandwidth for the latest and most powerful graphics cards. Storage is equally impressive, with multiple M.2 slots, including at least one with PCIe 5.0 support for blistering-fast NVMe SSDs. Networking is handled by a Realtek 2.5GbE LAN and the cutting-edge Wi-Fi 7 wireless standard, which offers superior speeds and lower latency for a flawless online experience. The board also features a comprehensive set of USB ports, including USB 3.2 Gen 2x2 and USB 3.2 Gen 2, to connect all your peripherals. With its robust build quality and a powerful set of features, the GIGABYTE X870 EAGLE WIFI7 is an excellent choice for building a high-performance system that is ready for the future.


Features of GIGABYTE X870 EAGLE WIFI7



  • AMD X870 Chipset: Supports the latest AMD Ryzen™ 9000, 8000, and 7000 Series processors.
  • Enhanced VRM Design: A robust digital power delivery system (VRM) to ensure stable and efficient power to the CPU, supporting reliable performance and mild overclocking.
  • DDR5 Support: Four DIMM slots accommodating up to 256GB of DDR5 memory, with support for overclocked speeds and AMD EXPO™ profiles.
  • PCIe 5.0 x16 Slot: A primary, reinforced PCIe 5.0 x16 slot for the latest high-performance graphics cards, offering maximum bandwidth.
  • Multiple M.2 Slots: Equipped with multiple M.2 slots for NVMe SSDs, likely including at least one PCIe 5.0 x4 slot for top-tier storage speeds and other PCIe 4.0 slots.
  • Wi-Fi 7: The latest wireless networking technology providing faster speeds, lower latency, and better reliability, with support for the 6 GHz band.
  • 2.5GbE LAN: A high-speed 2.5 Gigabit Ethernet port for a fast and stable wired network connection.
  • Comprehensive USB I/O: A rich selection of USB ports on the rear panel, including USB 3.2 Gen 2 and possibly USB 3.2 Gen 2x2 for high-speed peripheral connectivity.
  • Extended Heatsink Design: Provides larger surface area coverage for key components like the VRM and chipset, ensuring efficient heat dissipation.
  • M.2 Thermal Guard: Heatsinks for the M.2 SSD slots to prevent thermal throttling and maintain optimal performance.
  • Smart Fan 6: An advanced fan control system that allows users to precisely manage fan speeds through multiple temperature sensors and hybrid fan headers.
  • High-Quality Components: Built with durable capacitors and other components to ensure a long lifespan and stable operation.
  • Q-Flash Plus: A convenient feature that allows users to update the BIOS without the need for a CPU, RAM, or graphics card installed.
  • User-Friendly Layout: Designed for ease of installation, with a clear layout and logical placement of headers and slots.
