MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
-9 %
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
  • Price: 17,160৳
  • special price: 15,600৳
  • Status: In Stock
  • Brands: MSI
  • Model: MSI B550M Pro-VDH WiFi
Based on 0 reviews. - Write a review

Discount Price

15,600৳17,160৳
Available payment method

Monthly EMI Price

1,450৳
Ex Tax: 15,600৳
Add To Cart
Buy Now Add to Compare
Add to Wish List Compare this Product
  • AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
  • M.2 SHIELD FROZR
  • Supports DDR4 4400+ (OC)
  • PCB with 2OZ Thickened Copper
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
Basic Information
Supported CPU AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Chipset AMD B550
Form Factor Micro-ATX Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Audio Realtek ALC892 Codec 7.1-Channel High Definition Audio
Expansion Slots
PCI 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 2x PCIe 3.0 x1 slots
Memory
Type Dual-channel memory architecture
Slots 4x DDR4 memory slots
Supported Memory Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE 1DPC 1R max speed 4400 MHZ 1DPC 2R max speed 3733 MHZ 2DPC 1R max speed 3866 MHZ 2DPC 2R max speed 3466 MHZ Supports non-ECC UDIMM memory Supports ECC UDIMM memory Supports un-buffered memory
Maximum Memory 128GB
Graphics
Graphics 1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Connector & Ports
HDMI 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Display Port (s) 1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz
USB AMD B550 Chipset 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
LAN Port 1x Realtek 8111HN Gigabit LAN controller
Supported Storage AMD B550 Chipset 4x SATA 6Gb/s ports 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices
Internal I/O Ports 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 2x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 3x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 2x 4-pin RGB LED connectors 2x 3-pin RAINBOW LED connectors 1x Clear CMOS jumper
TPM (Trusted Platform Module ) 1 x TPM module connector
Others
Special Features WIRELESS LAN & BLUETOOTH: Intel Dual Band Wireless-AC 3168- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed. Supports Dual Mode Bluetooth 2.1,2.1+EDR,3.0,4.0,BLE,4.2
Warranty Information
Manufacturing Warranty 03 Years Warranty

MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

This Micro-ATX motherboard built on the AMD B550 chipset is a versatile and powerful platform designed for modern AMD Ryzen systems. It supports AMD Ryzen 5000 Series, 4000G Series, and 3rd Generation Ryzen processors, delivering excellent performance for gaming, productivity, and everyday computing. With a compact Micro-ATX form factor measuring 9.6 x 9.6 inches, it fits easily into a wide range of PC cases while still offering robust expandability.

The board features a strong expansion layout, including one PCIe 4.0/3.0 x16 slot for high-performance graphics cards and two PCIe 3.0 x1 slots for additional expansion cards. Storage options are comprehensive, with two M.2 (Key M) slots and four SATA 6Gb/s ports. The primary M.2 slot, connected directly to the processor, supports PCIe 4.0/3.0 x4 and SATA devices, while the secondary slot from the B550 chipset supports PCIe 3.0 x4, both accommodating 2242, 2260, and 2280 form factors.

Memory support is another highlight, offering four DDR4 slots with dual-channel architecture and a maximum capacity of 128GB. The motherboard supports a wide range of memory speeds, from standard JEDEC frequencies up to extreme overclocked speeds exceeding 4400 MHz via A-XMP OC mode, with compatibility for both ECC and non-ECC unbuffered memory.

For graphics output, it includes VGA, DisplayPort, and HDMI 2.1, supporting resolutions up to 4K at 60Hz, making it suitable for high-definition displays. Connectivity is well covered with multiple USB 3.2 Gen 1 and USB 2.0 ports, Gigabit LAN via Realtek 8111HN, and integrated Intel Dual Band Wireless-AC 3168 with Bluetooth support.

Additional features include 7.1-channel HD audio powered by the Realtek ALC892 codec, extensive internal headers for cooling, RGB lighting, TPM support, and a comprehensive set of internal I/O connectors. Backed by a 3-year manufacturing warranty, this motherboard offers a balanced combination of performance, connectivity, and reliability for modern PC builds.

MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

  • Supports AMD Ryzen 5000, 4000G, and 3rd Gen Ryzen processors for powerful and efficient performance.
  • AMD B550 chipset enables PCIe 4.0 support for faster graphics and storage speeds.
  • Dual M.2 slots with PCIe 4.0/3.0 support deliver ultra-fast NVMe storage performance.
  • Four DDR4 memory slots support up to 128GB RAM with speeds up to 4400+ MHz (OC).
  • HDMI 2.1, DisplayPort, and VGA outputs support up to 4K resolution at 60Hz.
  • Micro-ATX form factor offers a compact design with excellent expandability.
  • Integrated Intel dual-band Wi-Fi and Bluetooth provide fast wireless connectivity.
  • Realtek Gigabit LAN ensures stable and high-speed wired networking.
  • 7.1-channel HD audio powered by Realtek ALC892 for immersive sound quality.
  • Comprehensive cooling, RGB headers, and TPM support for modern PC builds.
